1. The structure of the receiver and transmitter

U8彩票The barrel adopts eccentric flat reducers, wheel paddle, clamp and lock ring type fast opening blind plate structure.

U8彩票A launcher is used to adjust the pipe cleaner to achieve the best position in the barrel and serve to prevent pipe cleaner, quick opening blind plate opens clear residual pressure in the pipe tube effect under the return tube is avoided. Do not go out in the barrel after the booster.

U8彩票2, materials

The cylinder body and the guide tube: Q345R, 16Mn, No. 20.

Fast opening blind plate: 16Mn III forging

U8彩票Seal: PTFE polyethylene rubber, Ding Qing

3, quality system

Implement ISO9001 quality certification system

4, norms and standards

The design, manufacture, inspection and acceptance of the service shall meet the requirements of the latest edition of the following codes and standards.

"Fixed pressure vessel safety technology supervision procedures" R0004-2009 TSG;

"Steel pressure vessel" GB150-2011

ASME CODE section 8

U8彩票"Steel pressure vessel - Analysis and design standards" JB4732-1995

U8彩票Saddle support the first part: saddle support, JB / T4712.1 - 2007

U8彩票"Steel chemical vessel design foundation" HG20580 - 2011

U8彩票"Selection of steel chemical vessel materials" HG20581 - 1998

"Steel chemical vessel strength calculation" HG20582 - 1998

U8彩票"Steel chemical vessel structure design" HG20583 - 2011

HG20584 - 2011 of steel chemical vessel manufacturing technology regulation

U8彩票"Flat washer a" GB97.1-2002

U8彩票"Long double headed stud B level" GB901-2010

"Type I six angle nut A and B level" GB/T6170-2000

U8彩票"Seamless steel butt welding pipe fittings" GB12459-2005

U8彩票"Nondestructive testing of pressure equipment" JB/T4730-2005

U8彩票Steel plate for boiler and pressure vessel GB713-2008

Second part of delivery technology for oil and gas industry conveying steel pipe: B grade steel pipe GB/T9711.2-1999

U8彩票"Seamless steel pipe for conveying fluid" GB8163-2008

U8彩票"Pressure vessel coating and transportation packaging" JB/T4711-2003

"General tolerance, linear dimension of the non - note tolerance" GB / T1804 - 2000

"With neck on welded pipe flange" B16.5 ANSI
